Baut Hexagon 9831717 Forklift Head CAP Screw M8 Stacker Pallet Mover Electric

Deskripsi

Baut
Part Number : 9831717
Direction of rotation of the thread RH/LH : right-handed
Metric diameter of the thread D1-M (mm) : 8
Thread size SIZE-TA1 : M8
Metric pitch of the thread Pm1 (mm) : 1.25
Metric length between head and end L1-M (mm) : 45
Total length of the bolt L3 (mm) : 53
Fully threaded FULL-TA : NO
Type of bolt head TY-HEA : B1
Type of bolt end TY-END : B1
Strength class CLASS-ST : 8.8
Type of material TY-MAT : steel
Metric width across flats WAF-M (mm) : 6
Unit of measurement MI : metric
Length of the thread L2 (mm) : 28
Largest thickness of the bolt head TH1 (mm) : 8
Minimum diameter of the head D2 (mm) : 13
Maximum diameter of the head D3 (mm) : 13
Description of the bolt DESC : socket head cap screw
Shape of the head of the bolt SH-HEA : B
Shape of the bolt end SH-END : B
DIN : 912
ISO : 4762
Weight : 50 gram
Mohon konfirmasi ketersediaan stok terlebih dahulu,
Dapat melalui chat atau diskusi
produk Gambar Asli
